Tplink TL-SG2008 Nigeria

Rating

Tplink TL-SG2008 Nigeria

Tplink TL-SG2008 Nigeria Smart Switch expands your office or business network capacity to handle a multitude of applications. With its 16 Gb/s switching capacity and 11.9 Mpps forwarding rate, Tplink TL-SG2008 provides smooth data transfers that are optimized for voice and video applications

Description

Tplink TL-SG2008 Network Switch Nigeria

Tplink TL-SG2008 Nigeria Smart Switch expands your office or business network capacity to handle a multitude of applications. With its 16 Gb/s switching capacity and 11.9 Mpps forwarding rate, Tplink TL-SG2008 Nigeria provides smooth data transfers that are optimized for voice and video applications. This managed switch features eight Gigabit Ethernet ports, one of which supports PoE in as an alternative to using the included AC power adapter when connected to compatible equipment. Your data is protected by a host of security features, including an Access Control List (ACL) and VLAN support. Use the Omada Software Defined Networking platform to manage your connected network devices and manage them remotely with the Omada app.

Features

  • Full Gigabit Ports: 8× gigabit RJ45 ports provide high-speed connections.
  • Integrated into Omada SDN: Zero-Touch Provisioning*, Centralized Cloud Management, and Intelligent Monitoring.
  • Centralized Management: Cloud access and Omada app for ultra-convenience and easy management.
  • Robust Security Strategies: 802.1Q VLAN, ACL, Port Security, Storm Control, and more.
  • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
  • Versatile Management: WEB/CLI managed modes, SNMP, and RMON bring abundant management features.

Software Defined Networking (SDN) with Cloud Access

Omada’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network—all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.

Centralized Management

The Omada Software Defined Networking (SDN) platform integrates access points, switches, gateways, and other network devices to provide high efficiency, security, and reliability.

Omada App

Configure, manage, and monitor your network devices from almost anywhere in the world using your smartphone or tablet.

Access Control List

Tplink TL-SG2008 Nigeria packs security features that allow or deny connected devices access to data with user-defined network rules.

Optimized Traffic

Configure the switch to prioritize voice and video traffic to help ensure clear calls and smooth media streaming.

VLAN Support

Group devices using VLAN to help improve network security and reduce data congestion.

Security Features

Tplink TL-SG2008 Nigeria protect your network from attacks and intrusions with IP-MAC-Port Binding, Access Control List, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1x, Radius Authentication, and more.

Quiet Operation

The metal chassis allows the switch to operate silently while dissipating heat.

Specifications

HARDWARE FEATURES
Standards and Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
Interface 8 10/100/1000Mbps RJ45 Ports (Auto-Negotiation/Auto MDI/MDIX)
Network Media
  • 10BASE-T : UTP category 3, 4, 5 cable (maximum 100m)
  • 100BASE-TX/1000Base-T : UTP category 5, 5e or above cable (maximum 100m)
Fan Quantity Fanless
Power Supply
  • 12 VDC/1 A External Adapter or
  • Obtain Power from PoE Source
Power Consumption 6.4 W (220 V/50 Hz)
Dimensions ( W x D x H ) 8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm)
PERFORMANCE
Bandwidth/Backplane 16 Gbps
Packet Forwarding Rate 11.9 Mpps
MAC Address Table 8K
Packet Buffer Memory 4.1 Mbit
Jumbo Frame 9 KB
SOFTWARE FEATURES
Quality of Service
  • 802.1p CoS/DSCP priority
  • 8 priority queues
  • Priority Schedule Mode
    • SP (Strict Priority)
    • WRR (Weighted Round Robin)
  • Queue Weight Config
  • Bandwidth Control
    • Port/Flow based Rating Limit
  • Smoother Performance
  • Storm Control
    • Multiple Control Modes(kbps/ratio)
    • Broadcast/Multicast/Unknown-Unicast Control
L2 and L2+ Features
  • 16 IP Interfaces
    • Support IPv4/IPv6 Interface
  • Static Routing
    • 32 IPv4/IPv6 Static Routes
  • DHCP Server
  • DHCP Relay
    • DHCP Interface Relay
    • DHCP VLAN Relay
  • DHCP L2 Relay
  • Static ARP
  • Proxy ARP
  • Gratuitous ARP
  • Link Aggregation
    • Static link aggregation
    • 802.3ad LACP
    • Up to 8 aggregation groups and up to 8 ports
  • per group
  • Spanning Tree Protocol
    • 802.1D STP
    • 802.1w RSTP
    • 802.1s MSTP
    • STP Security : TC Protect, BPDU Filter/Protect,
  • Root Protect
  • Loopback Detection
  • Flow Control
    • 802.3x Flow Control
  • Mirroring
    • Port Mirroring
    • CPU Mirroring
    • One-to-One
    • Many-to-One
    • Flow-Based
    • Ingress/Egress/Both
  • Device Link Detect Protocol (DLDP)
  • 802.1ab LLDP/ LLDP-MED
VLAN
  • VLAN Group
    • Max. 4K VLAN Groups
  • 802.1Q tag VLAN
  • MAC VLAN : 12 Entries
  • Protocol VLAN
  • GVRP
  • Voice VLAN
Access Control List
  • Support up to 230 entries
  • Time-Range
    • Time Slice
    • Week Time-Range
    • Absolute Time-Range
    • Holiday
  • Time-based ACL
  • MAC ACL
    • Source MAC
    • Destination MAC
    • VLAN ID
    • User Priority
    • Ether Type
  • IP ACL
    • Source IP
    • Destination IP
    • IP Protocol
    • TCP Flag
    • TCP/UDP Source Port
    • TCP/UDP Destination Port
    • DSCP/IP TOS
  • IPv6 ACL
  • Combined ACL
  • Rule Operation
    • Permit/Deny
  • Policy Action
    • Mirror
    • Rate Limit
    • Redirect
    • QoS Remark
  • ACL Rules Binding
    • Port Binding
    • VLAN Binding
  • Actions for flows
    • Mirror (to supported interface)
    • Redirect (to supported interface)
    • Rate Limit
    • QoS Remark
Security
  • AAA
  • 802.1X
    • Port based authentication
    • MAC (Host) based authentication
    • Authentication Method includes PAP/EAP-MD5
    • MAB
    • Guest VLAN
    • Support Radius authentication and
  • accountability
  • IP/IPv6-MAC Binding
    • 512 Binding Entries
    • DHCP Snooping
    • DHCPv6 Snooping
    • ARP Inspection
    • ND Detection
  • IP Source Guard
    • 253 Entries
    • Source IP+Source MAC
    • IPv6 Source Guard
    • 183 Entries
    • Source IPv6 Address+Source MAC
  • DoS Defend
  • Static/Dynamic/Permanent Port Security
    • Up to 64 MAC addresses per port
  • Broadcast/Multicast/Unicast Storm Control
    • kbps/ratio control mode
  • Port Isolation
  • Secure web management through HTTPS with
  • SSLv3/TLS 1.2
  • Secure Command Line Interface (CLI)
  • management with SSHv1/SSHv2
  • IP/Port/MAC based access control
Management
  • Web-based GUI
  • Command Line Interface (CLI) through telnet
  • SNMPv1/v2c/v3
  • SNMP Trap/Inform
  • RMON (1,2,3,9 groups)
  • SDM Template
  • DHCP/BOOTP Client
  • Dual Image, Dual Configuration
  • CPU Monitoring
  • Cable Diagnostics
  • EEE
  • SNTP
  • System Log
Advanced Features
  • Automatic Device Discovery
  • Batch Configuration
  • Batch Firmware Upgrading
  • Intelligent Network Monitoring
  • Abnormal Event Warnings
  • Unified Configuration
  • Reboot Schedule
MANAGEMENT
Omada App Yes, through

  • Omada Cloud-Based Controller (Not Supported by TL-SG2428P v2)
  • OC300
  • OC200
  • Omada Software Controller
Centralized Management
  • Omada Cloud-Based Controller (Not Supported by TL-SG2428P v2)
  • Omada Hardware Controller OC300
  • Omada Hardware Controller OC200
  • Omada Software Controller
Cloud Access Yes, through

  • Omada Cloud-Based Controller (Not Supported by TL-SG2428P v2)
  • OC300
  • OC200
  • Omada Software Controller
Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller (Supported by TL-SG2428P v1, v3 and above, while is not supported by TL-SG2428P v2)
Management Features
  • Web-based GUI
  • Command Line Interface (CLI) through telnet
  • SNMPv1/v2c/v3
  • SNMP Trap/Inform
  • RMON (1,2,3,9 groups)
  • SDM Template
  • DHCP/BOOTP Client
  • Dual Image, Dual Configuration
  • CPU Monitoring
  • Cable Diagnostics
  • EEE
  • SNTP
  • System Log
OTHERS
Certification CE, FCC, RoHS
Package Contents
  • TL-SG2008
  • Power Adapter
  • Installation Guide
  • Rubber Feet
System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux.
Environment
  • Operating Temperature : 0℃~40℃ (32℉~104℉);
  • Storage Temperature : -40℃~70℃ (-40℉~158℉)
  • Operating Humidity : 10%~90% non-condensing
  • Storage Humidity : 5%~90% non-condensing
